MC² X06 X-Over Card

Introduction
Plug-in crossover cards are available for all our amplifiers.  These can be set to your specified filter/frequency (24dB/octave Linkwitz Riley).
Each channel is independent and can be configured as a High Pass (HPF), Low Pass (LPF), or Band Pass filter (BPF).

The range of possible frequencies is from 20Hz to 15kHz.

Any channel can alternatively be configured as a HPF at 24dB/octave with a phase adjustment centered on the crossover frequency. Each channel has a bypass link facility for enabling or disabling the filter.

Note: The channel link facility on some of our amplifiers does not allow one filter to serve more than one channel.
